Generated Hub Client

When you define a SignalR interface with the [HubClient] attribute, SignalRGen automatically generates a strongly-typed client class for you. This page explains what gets generated and how to use the resulting client.

Interface to Client: The Transformation Process

Let's examine how SignalRGen transforms your interface definition into a usable client class.

Starting with an Interface

Here's a typical SignalR interface definition:

csharp

using SignalRGen.Abstractions;
using SignalRGen.Abstractions.Attributes;

namespace SignalRGen.Example.Contracts;

[HubClient(HubUri = "chat")]
public interface IChatHubContract : IBidirectionalHub<IChatHubServerToClient, IChatHubClientToServer>
{
}

public interface IChatHubServerToClient
{
    Task UserJoined(string user);
    Task UserLeft(string user);
    Task MessageReceived(string user, string message);
}

public interface IChatHubClientToServer
{
    Task SendMessage(string message);
}

Generated Client Class

From this interface, SignalRGen generates a class named ChatHubContractClient (removing the "I" prefix from the interface name and suffix it with "Client"). This class provides:

Event-based pattern for server-to-client methods
Strongly-typed methods for client-to-server calls
Connection management functionality

Hub Client Features

Connection Management

Each generated hub client includes methods to manage the SignalR connection:

csharp

// Start the connection
Task StartAsync(
      Dictionary<string, string>? queryStrings = null,
      Dictionary<string, string>? headers = null,
      CancellationToken cancellationToken = default);

// Stop the connection
Task StopAsync(CancellationToken cancellationToken = default);

// Disposes the connection
ValueTask DisposeAsync();

Server-to-Client Methods

For each method in your TServer interface (in the example above the IChatHubServerToClient interface) SignalRGen generates an event that you can subscribe to:

csharp

// For the interface method:
// Task UserJoined(string user);

// SignalRGen generates:
public Func<string, Task>? OnUserJoined = default;

The naming convention is to add the "On" prefix to the original method name.

Client-to-Server Methods

For each method in your TClient interface (in the example above the IChatHubClientToServer interface), SignalRGen generates a method that calls the server:

csharp

// For the interface method:
// Task SendMessage(string message);

// SignalRGen generates:
public Task InvokeSendMessageAsync(string message, CancellationToken ct = default)
{
    ValidateHubConnection();
    return _hubConnection!.InvokeAsync("SendMessage", message, cancellationToken: ct);
}

The naming convention is to add the "Invoke" prefix and "Async" suffix to the original method name.

Using the Generated Client

Dependency Injection

csharp

// In Program.cs or Startup.cs
services.AddSignalRHubs(options =>
{
    options.HubBaseUri = new Uri("https://your-api.example.com/hubs");
})
.WithChatHubContractClient();  // Method name follows the pattern With[ClientName]

💡 Changing AddSignalRHubs naming

You can change the naming of the AddSignalRHubs method by supplying a SignalRModuleName in your csproj:

csharp

    <Project Sdk="Microsoft.NET.Sdk">
      <PropertyGroup>
        <TargetFramework>net9.0</TargetFramework>
        <SignalRModuleName>Chat</SignalRModuleName>
      </PropertyGroup>

      // This here is important to expose the property to the source generator
      <ItemGroup>
        <CompilerVisibleProperty Include="SignalRModuleName" />
      </ItemGroup>

      <!-- Your SignalRGen package references -->
    </Project>

This also allows you to use the AddSignalRHubs method in multiple projects. See Multi-Project Support for more information.

Basic Usage

Here's how to use the generated client in your application:

csharp

public class ChatService
{
    private readonly ChatHubContractClient _hubClient;
    private readonly ILogger<ChatService> _logger;

    public ExampleService(ChatHubContractClient hubClient, ILogger<ExampleService> logger)
    {
        _hubClient = hubClient;
        _logger = logger;
    }

    public async Task Initialize()
    {
        // Subscribe to server-to-client events
        _hubClient.OnUserJoined += user =>
        {
            _logger.LogInformation("User '{Username} joined", user);
            return Task.CompletedTask;
        };

        // Start the connection
        await _hubClient.StartAsync();
    }

    public async Task SendMessage(string message)
    {
        // Call the method to send data to the server
        await _hubClient.InvokeSendMessageAsync(_message);
    }

    public async Task Cleanup()
    {
        // Unsubscribe from events
        _hubClient.OnUserJoined = null;

        // Stop the connection
        await _hubClient.StopAsync();
    }
}

Connection Events

The generated client also exposes events for connection state changes:

csharp

// Subscribe to connection events
_hubClient.Reconnecting += error =>
{
    logger.LogWarning("Reconnecting due to: {Error}", error?.Message);
    return Task.CompletedTask;
};

_hubClient.Reconnected += connectionId =>
{
    logger.LogInformation("Reconnected with ID: {ConnectionId}", connectionId);
    return Task.CompletedTask;
};

_hubClient.Closed += error =>
{
    logger.LogWarning("Connection closed due to: {Error}", error?.Message);
    return Task.CompletedTask;
};

Client Lifecycle

Understanding the lifecycle of the generated hub client is important for proper usage:

Registration: The hub client is registered with your DI container when you call .WithChatHubContractClient()
Injection: The hub client is injected into your service
Event Setup: Subscribe to server-to-client events before starting the connection
Connection: Call StartAsync() to establish the connection
Usage: Call client-to-server methods and handle server-to-client events
Cleanup: Unsubscribe from events and call StopAsync() when done or use the auto-dispose provided by the DI container

By default, the hub client is registered as a Singleton, but you can change this using the configuration options.

Working with Complex Types

SignalRGen supports complex types in both directions:

csharp

[HubClient(HubUri = "complex-example")]
public interface IComplexTypeHubContract : IBidirectionalHub<IComplexTypeHubServerToClient, IComplexTypeHubClientToServer>
{
}

public interface IComplexTypeHubServerToClient
{
    // Server-to-client with complex type
    Task ReceiveComplexData(MyCustomType data);
}

public interface IComplexTypeHubClientToServer
{
    // Client-to-server with complex type
    Task<MyCustomType> SendComplexData(MyCustomType data);
}

public record MyCustomType(string Hey, int Dude);

The generated client handles serialization and deserialization of these types automatically.

Best Practices

Event Handling:
- Always return Task.CompletedTask from event handlers if they don't perform async operations
- Consider using weak event patterns for long-lived connections to prevent memory leaks
Connection Management:
- Start connections when your application initializes, not on-demand for each operation
- Calling StartAsync after the connection was already started does not fail, a Task.CompletedTask will be returned
- StartAsync, StopAsync and DisposeAsync are NOT threadsafe
- Use the Reconnecting, Reconnected, and Closed events to handle connection issues
Resource Cleanup:
- Always stop connections when they're no longer needed
- Unsubscribe from events before stopping connections
Testing:
- Create test doubles (mocks/fakes) for the generated client to test your application logic

Technical Details

The generated client:

Uses Microsoft's HubConnection under the hood
Implements automatic reconnection with configurable retry policies (see default retry settings)
Provides thread-safe event invocation
Handles connection lifecycle and state management
Uses asynchronous patterns throughout for non-blocking operation

Troubleshooting

Common issues and solutions:

Connection fails to establish:
- Verify the HubBaseUri is correct
- Check if the server is running and accessible
- Ensure proper authentication is configured if required
Events not firing:
- Verify you've subscribed to events before starting the connection
- Check if the connection is in the Connected state
- Ensure server methods are calling the correct client methods
Method invocation fails:
- Verify the connection is in the Connected state
- Check for parameter type mismatches
- Ensure proper authentication/authorization

For more detailed diagnostic information, enable SignalR logging:

csharp

.WithChatHubContractClient(options =>
{
    options.HubConnectionBuilderConfiguration = builder =>
    {
        builder.ConfigureLogging(logging =>
        {
            logging.AddConsole();
            logging.SetMinimumLevel(LogLevel.Debug);
        });
    };
})
